Name: Pneumatic Double Head Round Corner Cutting Machine with 100mm Cutting Thickness 23 times/min Working Speed and 490*450mm Max Paper Size
Brand: DONGGUAN MAUFUNG MACHINERY CO.,LTD
Price: 8.00 USD
Availability: InStock

Startseite Produkte Notebook-Bindemaschine

Pneumatic Double Head Round Corner Cutting Machine with 100mm Cutting Thickness 23 times/min Working Speed and 490*450mm Max Paper Size

Produktdetails:

Herkunftsort:	Guangdong, China
Markenname:	MAUFUNG

Zahlung und Versand AGB:

Min Bestellmenge:	1
Preis:	$8,000-9,000

Kontakt

Ausführliche Produkt-Beschreibung

Leistung:	1,5 kW	Stromspannung:	220 V/50 Hz
Dimension:	9608701390mm	Gewicht:	220 kg
Dicke schneiden:	100 mm	Arbeitsgeschwindigkeit:	23 mal/min
Min Papiergröße:	105*50 mm	Maximale Papiergröße:	490*450 mm
Funktionstabellengröße:	860*380 mm	Luftdruck:	6-8bar
Runde Eckform:	1/8'',3/16'',1/4'',5/16'',3/8'',7/16'',1/2''	Automatische Note:	Automatisch
Maschinenabmessungen:	9608701390mm	Nettogewicht:	220 kg
Modell Nr:	MF-DCM470
Hervorheben:	100mm Cutting Thickness Round Corner Cutting Machine , 23 times/min Working Speed Book Cutting Machine , 490*450mm Max Paper Size Notebook Cutting Machine

Pneumatic Double Head Angle Cutting Machine Book Round Corner Cutting Machine Notebook Cutting Machine

Product Specifications

Model No	MF-DCM470
Power Supply	220V /50HZ
Max Paper size	490*450mm
Min Paper size	105*50mm
Max cutting thickness	100mm
Round corner mold	1/8''，3/16''，1/4''，5/16''，3/8''，7/16''， 1/2''，9/16''，5/8''，3/4''，7/8''， 1'
Working Table size	860*380mm
Air pressure	6-8bar
Machine Dimensions (LWH)	9608701390mm
Working Speed	23 times/min
Weight	220kg

Pneumatic double head with max cutting 100mm thickness.

Touch screen for convenient operation.

Applications

MF-DCM470 Hydraulic Double-head Angle Cutting Machine applies to books, playing cards, invitations, trademarks, business cards and other printing and cutting round, triangle shape. This machine uses hydraulic system. It can cut two sides of angles one time with simple operation and high efficiency.
